20mph
Top assisted speed
Up to 49 Mile Range
High range Rev ebike
5 Pedal Assist Levels
Propel while pedaling
.svg?v=1704905965623&options=)
750W
Planetary geared hub motor
.svg?v=1704905967137&options=)
48V/500Wh
LG Li-ion battery
Tektro Mechanical Disc Brakes
Consistent & confident stopping power
4” Fat Tires
Superior puncture protection for any terrain
350 lbs
Recommended weight limit
UL2849 Certified
Safety tested and approved by a UL accredited lab
Specification
FRAMESET
- FrameValen 6061 hydroformed aluminum with, external downtube battery and replacable derailleur hanger.
- ForkRigid Triple Clamp Steel fork.
WHEELSET
- Rims20″ single-wall aluminum 36H, for disck brake
- Front Hub: Aluminum bolt-on with 17mm axle nuts. 36 hole
- Spokes13G w/brass nipples
- Tires: 20×4″ Fat MTB with puncture protection and reflective sidewall
E-POWER SYSTEM
- Motor750W rear hub
- Battery500Wh/48VLG 21700 cells; Charge on or off bike
- DisplayLeft mounted color LED
- Charger48V/2A
- 48V/750W rangeUp to 49 miles
- Assist Levels1-5 PAS, Throttle and walk-mode
DRIVETRAIN
- Crankset3-Piece aluminum w/steel 38T chainrings with double alloy chainguard
- ChainKMC SIngle Speed
- BBSealed cartridge
- Freewheel/CogSingle Speed 18T
COMPONENTS
- Headset1-1/8” semi-integrated threadedless
- BrakesTektro lever with Tektro mechanical caliper with 180mm rotors and semi-metalic pads
- HandlebarsSteel BMX
- GripsLock-on comfort grips.
- StemBMX Die Cast Alloy 22.2mm clamp
- SaddleRetrospec Custom Moto
- PedalsPP plateform with non-slip tread
EXTRAS
- KickstandAluminum chainstay mounted, 40MM bolt pattern
- Item Weight72 lbs (battery included)
- Recommended Weight Limit350lbs
