Overview
-
80 Miles
Per Charge (maximum) 1
-
750 W
Geared Hub Motor
-
960 Wh
Samsung/LG Battery
-
7-Speed
Shimano Derailleur
-
440 lb.
Payload Capacity
-
Hydraulic
Brakes
-
20×3 “
CST Tire
-
20+ Mph
Top Speed 2
- 1 – The range can be affected by several factors like rider weight, incline, and pedal-assist levels, etc.
Specs
-
A – total length70.4
-
B – handlebar height42
-
C – handlebar length28.4
-
D – wheelbase47.2
-
E – wheel diameter23
-
F – minimum seat height34
-
G – maximum seat height40
-
H – chain stay length23
-
I – frame stack31.9
-
K – effective top tube length17
-
L – head tube length8.1
-
N – standover height19
Specification
-
Frame6061 Aluminum frame
-
HeadsetNeco H114 28.6*44*30
-
ForkTRAMA coil suspension 60mm travel 135mm thru axle
-
Front wheelRim: J57SA 20*12G*36H A/V | Spoke: 12G 172mm | Hub: MB016F-92-T 15*135mm 12G*36H
-
Rear wheelRim: J57SA 20*12G*36H A/V | Spoke: 12G 127mm/128mm | Hub: 48v 750w Himiway Hub Motor
-
TiresCST 20″x3″
-
BatterySamsung/LG 48V 20Ah
-
Motor750W brushless gear motor
-
DisplayHimiway C2 LCD Display
-
ThrottleThumb throttle
-
SensorsTorque sensor丨speed sensor丨brake sensor
-
Crankset44T BCD104 6061-T6 145mm
-
FreewheelShimano MF-TZ500-7 14-28T
-
ChainKMC Z8.3 EPT 120L
-
GroupsetShimano altus M310 7 speed
-
Front wheel“Rim: MD-147 20*4.0″”*36H*12G A/V | Spoke: 12G 171mm/173mm | Hub: MB016F-92-T 15*135MM 12G*36H”
-
Rear wheelRim: MD-147 20*4.0″”*36H*12G A/V | Spoke: 12G 126mm/127mm Hub: 48v 750w | Himiway Hub Motor
-
RotorsF:180mm R:180mm
-
Rear brakeTektro HD-E3520 hydraulic brake
Components
-
Stem3D forged alloy Ext:40mm
-
HandlebarYC-B086 22.2*31.8*720mm
-
SaddleHimwiay saddle
-
PedalAluminum pedal
-
KickstandHeavy-duty aluminum kickstand
Others
-
Range60-80 miles
-
Controller48V/22A
-
ChargerUS standard 3.0 A smart charger
-
Rider height5’2″ ~ 6’3″
-
Weight80 lb. (with battery)
-
Max. system weight440 lb. (with battery)
